Scissor Lift 40H x 47W 46ft Working
Note: prices are subject to change. To check availability, request a reservation, and obtain final pricing contact us at (636) 349-1141.
-
Genie GS4047
-
Working height maximum: 44’ 4.6”
Platform height maximum: 38’ 4.6”
Platform height: 4’ 8.3” (stowed)
Platform length: 7’ 5” / 10’ 5” (extended
Platform width: 3’ 9.5” (outside)
Guardrail height: 3’ 7”
Toeboard height: 6”
Height: 8’ 4” (stowed)
rails lowered: 6’ 5”
Length: 8’ 2” (stowed) / 11’ 1” (extended)
Width: 3’ 11”
Wheelbase: 6’ 1”
Ground clearance: 4” (centered) / .75” (pothole guards deployed)
Lift capacity: 770 lbs
Drive height: full height
Drive speed: 2 mph (stowed)
Drive speed: 0.5 mph (raised)
Gradeability: 25% (stowed)
Turning radius: inside zero
Turning radius: 91” (outside)
Raise/lower speed: 71/41 sec
Controls proportional
Duel drive front wheels
Multiple disc brakes dual rear wheel
Tyres solid non-marking: 15” x 5” x 11”
Power source: 24 V DC, 300 Ah (four 12 V, 150 Ah batteries in parallel series)
Weight: 7103 lbs
