Articulating Bucket Lift 55ft
from $177.00
Note: prices are subject to change. To check availability, request a reservation, and obtain final pricing contact us at (636) 349-1141.
Duration:
Quantity:
-
-
Haulotte 5533A
-
Working height: 61’ 3”
Platform height: 55’ 3”
Horizontal outreach: 33’ 5” (from center) 27’ 4” (from edge of footpad)
Up and over height: 23’ 1”
Lift capacity: 500 lbs
Dimensions: L 23’ 8” x W 5’ 7” x H 6’ 9”
Platform size: 4’ 1” x 2’ 9”
Turnable rotation: 350 degree non-continuous
Jib vertical motion: 150 degrees (+70/-80)
Tow speed rating: 65 mpg
Leveling capability: 12.5 degrees
Power source: 4 x 6v 245 amp/hr
Weight: 4,800 lbs
Widest Point: 15’
